MANKIND NXS XL 20 Bike Ed Black

The Mankind NXS Bike combines great looks with amazing specs! The NXS is our most popular model being a perfect model to start riding at a great price point. The NXS is available 18” and 20”. The NXS 20” is further available in XS: 18.5” (130cm to 150cm), JR: 20.0” (150cm to 170cm), 20.5” (170cm to 180cm) and XL: 21.0” (from 185cm) Top Tube versions, making it easy for you to find the size you need. Connect with the NXS to begin your journey into the world of BMX!

Key features:

Mankind Control Grips

Chromoly 3-Piece Cranks

Mankind Control Steel Sprocket 25t

Sealed Integrated Headset

Sealed Mid BB

Geometry:

Top Tube Length: XS: 18.5“, JR: 20.0″, 20.5“, XL: 21.0“

Chain Stay Length: 13.25″

Head Tube Angle: 75.0°

Stand Over Height: 8.5″ (XS:8.0“)

Bar Height: XS: 8.2“, JR: 8.5“, NXS & NXS XL: 8.75“

Fork Offset: 28mm

Weight: 10.7 kg / 23.59 lbs for NXS

Colors:

NXS XS: Gloss Black, Gloss Blue,

NXS JR: Gloss Black, Off White

NXS: Gloss Black, Gloss Metallic Blue, Gloss Grey,

NXS XL: Gloss Black, Gloss Raw

FRAME 1020 Hi-Ten Steel Frame – Top & Down Tube Gusset

TOP TUBE XS: 18.5”, JR: 20.0”, NXS: 20.5”, XL: 21.0”

CHAIN STAY 13.25”

HEAD TUBE 75°

SEAT TUBE 71°

BB HEIGHT 11.5”

STAND OVER 8.5” (XS: 8.0”)

BRAKE MOUNTS Welded

FORK 1020 Hi-Ten Steel – 1-PC Steerer, Tapered Legs, 28mm offset

BARS 1020 Hi-Ten Steel, XS:8.2”,JR:8.5”,NXS&XL:8.75”,12°/ 2°,28.5”

GRIPS Mankind Control Grips

BAR ENDS Mankind Nylon

STEM Mankind Control Top Load Stem – Alloy – 50mm reach

HEADSET Mankind Control Sealed Integrated

BRAKE Alloy U-brake

BRAKE LEVER Alloy Lever – 2-Finger Design

REAR HUB Mankind Control Cassette Hub – Sealed – 14mm axle – 9t Driver

FRONT HUB Alloy – Loose Ball – 3/8” axle

SPROCKET Mankind Control Steel 25t

CRANKS Chromoly – 8 Spline – 3-Piece – 170mm – 19mm (XS:165mm)

BOTTOM BRACKET Mid BB Sealed – 19mm

CHAIN PYC 410 – black

PEDALS Plastic Platform

FRONT RIM 6061 Alloy – Single Wall 36H

REAR RIM 6061 Alloy – Single Wall 36H

SPOKES Steel Spokes – 14mm nipples – black

FRONT TIRE Park/Street Tire LP 60 PSI – 2.3”

REAR TIRE Park/Street Tire LP 60 PSI – 2.3”

PEGS None

SEAT Mankind NXS Mid Seat/Post Combo

SEAT POST Seat/Post Combo

SEAT POST CLAMP Mankind Control Alloy – black

COLORS

NXS XS: Ed Black, Gloss Blue

NXS JR: Ed Black, Gloss Off White

NXS: Ed Black, Gloss Metallic Blue, Gloss Grey

NXS XL: Ed Black, Gloss Trans Raw

WEIGHT 10,70 kg
